Geared to your Compliance
Geared to your compliance, EMC Partner provides a comprehensive range of test solutions. We are the UK representatives for EMC Partner Ag, Frankonia GmbH, AFJ Instruments and Schwarzbeck Messe Systems.
Specialist products include turnkey solutions for DO-160, Boeing and Airbus standards. CE marking and safety standards. As well as IEC and CISPR requirements.
Our modular generators include, ESD, EFT SURGE, DIPS and Variation. As well as, Magnetic field, 3Phase and many more applications and accessories.
Alternatively, our product portfolio includes conducted and radiated immunity solutions in accordance with EN 61000-4-3 and EN 61000-4-6.
Radiated and Conducted emission measurements. Are performed by our ultra modern FFT digital EMI receivers. Last but not least, Schwarzbeck offer the largest portfolio of antenna and LISN designs.
IMU-MGE
CIT-100
All in one conducted RF immunity system in accordance with EN 61000-4-6.
Wide range of CDN's EM clamp or BCI injection devices.
IMU-MGS
AVI-LV5
AVI-LV5 is a powerful level 5 system. That includes all waveforms for RTCA DO-160: Section 22 and MIL-STD-461G: CS117 testing. All event types are available for PIN Injection and Cable Bundle tests.
Combined with only two couplers, AVI-LV5 is a compact and resourceful solution to indirect lightning effects testing needs.
A smart solution: AVI-LV5 comes with the latest Version of EPOS. The Operating system from EMC PARTNER offering predefined test routines, customizable report functions and a deeply customizable parameter editing. Operation can be done directly on the generator's touch screen or via the comfortable TEMA3000 software test suite.
AVI-LV3
DOW-CG1
EMC PARTNER introduces an all new high voltage test system for damped oscillatory wave testing.
DOW-CG1 is a configurable test system that can be extended for Slow Wave, Fast Wave, Impulse voltage test or any combination of all three.
This provides optimum and cost efficient capabilities to a wide spectrum of users. This unique system includes an integrated 32A three phase coupler which enables both Slow and Fast DOW signals to be directly injected into the EUT. Additionally, DOW-CG1 is the first tester with integrated 0.5J impulse, required together with the DOW, for product standard testing.
A modern user interface provides an easy to follow menu structure. Graphic and contextual help functions make operation simple and efficient.
EFS-Laser
FFT 3010 & FFT 3030
Frankonia's EFS-Laser cover the frequency-range from 10 KHz – 6 GHz. The utilized linearization technology provides a dynamic range up to 100 dB. The EFS-Laser is a smart, fast, extremely accurate electric field probe, which provides linearization, temperature compensation, control and communication functions. Noise reduction and temperature compensation allow accurate measurements down to 0.1 V/m. The probe is laser-powered to allow continuous, galvanically isolated operation without recharging or battery replacement The power supply unit comes in a small handy box.
Compact unit designed and manufactured compliant to CISPR 16-1-1;
-
FFT Scan Mode compliant to CISPR 16-3;
-
Peak, Quasi-Peak, CISPR Average, RMS and CISPR RMS Detectors;
-
Pre-selectors;
-
Tracking Generator;
-
Advanced software for EMC testing;
-
1Hz PRF CISPR 16-1-1 calibrated pulse weighting.
Frankonia FAC3 Chamber
The FAC-3 is Frankonia’s fully anechoic chamber solution (FAR) at 3,0m measuring distance for EMC tests on table top positioned EUT’s. It is designed as full compliant chamber for measurements under free-space conditions and is based on CISPR 16-1-4 as a test site without ground plane. Without the reflections from the floor, a height scan is no longer necessary. With its specific requirements for the test site, Frankonia’s FAC-3 is supremely prepared to meet our customers’ demands.
ESD3000
AA Battery operated handheld ESD Simulator up to 30kV. Modular design with networks for a broad range of standards and applications.
AA battery operated and light weight ElectroStatic Discharge (ESD) generator. Available as 16 kV version upgradeable to 30 kV. Modular architecture with networks for household and industrial electronics, automotive, defence and avionic applications. Fully compliant to most populat standards including IEC 61000-4-2, ISO 10605, MIL-STD-461 CS118 and DO-160 section 25.
